- 35 degrees rotation angle and rapid return stroke for fast operation
- Tough manifold design with added safety feature for enhanced operator safety
- 360Âdeg click-on reaction arm with quick release lever provides easier handling, even when wearing gloves
- Push button square drive release for quickly reversing the square drive for tightening or loosening

Nominal Torque at 690 bar: 8338 Nm
Minimal Torque at 69 bar: 834 Nm
Square Drive Size: 38mm - 1 1/2"

Nominal Torque at 69 bar:
835 Nm

 615 ft-lb
Nominal Torque at 83 bar:
1004 Nm

 740 ft-lb
Nominal Torque at 97 bar:
1173 Nm

 865 ft-lb
Nominal Torque at 110 bar:
1330 Nm

 981 ft-lb
Nominal Torque at 124 bar:
1500 Nm

 1106 ft-lb
Nominal Torque at 138 bar:
1669 Nm

 1231 ft-lb
Nominal Torque at 152 bar:
1838 Nm

 1356 ft-lb
Nominal Torque at 166 bar:
2008 Nm

 1481 ft-lb
Nominal Torque at 179 bar:
2165 Nm

 1597 ft-lb
Nominal Torque at 193 bar:
2334 Nm

 1722 ft-lb
Nominal Torque at 207 bar:
2504 Nm

 1846 ft-lb
Nominal Torque at 221 bar:
2673 Nm

 1971 ft-lb
Nominal Torque at 234 bar:
2830 Nm

 2087 ft-lb
Nominal Torque at 248 bar:
3000 Nm

 2212 ft-lb
Nominal Torque at 262 bar:
3169 Nm

 2337 ft-lb
Nominal Torque at 276 bar:
3338 Nm

 2462 ft-lb
Nominal Torque at 290 bar:
3508 Nm

 2587 ft-lb
Nominal Torque at 303 bar:
3665 Nm

 2703 ft-lb
Nominal Torque at 317 bar:
3834 Nm

 2828 ft-lb
Nominal Torque at 331 bar:
4004 Nm

 2952 ft-lb
Nominal Torque at 345 bar:
4173 Nm

 3077 ft-lb
Nominal Torque at 359 bar:
4342 Nm

 3202 ft-lb
Nominal Torque at 372 bar:
4499 Nm

 3318 ft-lb
Nominal Torque at 386 bar:
4669 Nm

 3443 ft-lb
Nominal Torque at 400 bar:
4838 Nm

 3568 ft-lb
Nominal Torque at 414 bar:
5007 Nm

 3693 ft-lb
Nominal Torque at 428 bar:
5177 Nm

 3818 ft-lb
Nominal Torque at 441 bar:
5334 Nm

 3934 ft-lb
Nominal Torque at 455 bar:
5503 Nm

 4059 ft-lb
Nominal Torque at 469 bar:
5673 Nm

 4183 ft-lb
Nominal Torque at 483 bar:
5842 Nm

 4308 ft-lb
Nominal Torque at 497 bar:
6011 Nm

 4433 ft-lb
Nominal Torque at 510 bar:
6169 Nm

 4549 ft-lb
Nominal Torque at 524 bar:
6338 Nm

 4674 ft-lb
Nominal Torque at 538 bar:
6507 Nm

 4799 ft-lb
Nominal Torque at 552 bar:
6677 Nm

 4924 ft-lb
Nominal Torque at 566 bar:
6846 Nm

 5049 ft-lb
Nominal Torque at 579 bar:
7003 Nm

 5165 ft-lb
Nominal Torque at 593 bar:
7173 Nm

 5289 ft-lb
Nominal Torque at 607 bar:
7342 Nm

 5414 ft-lb
Nominal Torque at 621 bar:
7511 Nm

 5539 ft-lb
Nominal Torque at 634 bar:
7668 Nm

 5655 ft-lb
Nominal Torque at 648 bar:
7838 Nm

 5780 ft-lb
Nominal Torque at 662 bar:
8007 Nm

 5905 ft-lb
Nominal Torque at 676 bar:
8176 Nm

 6030 ft-lb
Nominal Torque at 690 bar:
8346 Nm

 6155 ft-lb
