HYDRAULIC CYLINDER 15T / 152MM Print to PDF

Code: 307705
  1. HYDRAULIC CYLINDER  15T / 152MM - code:307705
  2. HYDRAULIC CYLINDER  15T / 152MM - code:307705

For various applications involved with lifting, pulling, pushing, bending,  load testing or clamping.


GET QUOTE / CHECK AVAILABILITY
PLANT COMPLIANCE

Make: ENERPAC
Model: RC156
Dry Weight: 6.8kg
Capacity: 15T / 152mm
- Lightweight, low profile design for use in confined spaces
- Baked enamel finish for increased corrosion resistance
- Plunger wiper reduces contamination, extending cylinder life
- CR-400 coupler and dust cap included on all models
- Grooved plunger end with threaded holes for mounting tilt saddles
- Integral handle on RCS-1002 for easy carrying
- Plated steel plungers
- Single-acting spring return
Cylinder Capacity: 2015(142) ton (kN)
Stroke: 152mm
Cylinder Effective Area: 20.3cm2
Oil Capacity: 308cm3
Collapsed Height: 271mm
BROCHURE
OPERATING MANUAL
INSURANCE

A ute is suitable
Safety Boots Required
Protective gloves

*Product availability may be subject to fluctuation
*EQUIPMENT shown may not necessarily be in stock and immediately available and specifications may vary between models. Pictures shown are for illustration purposes only.
