- Compact hydraulic cylinder wtih a flat design for use where most other cylinders will not fit
- Single-acting, spring return
- Mounting holes permit easy fixturing
- Baked enamel finish for increased corrosion resistance
- Hard chrome plated high quality steel plungers
- Grooved plunger ends require no saddle.

Cylinder Capacity: 20 (201) ton (kN)
Stroke: 11mm
Cylinder Effective Area: 28.7cm2
Oil Capacity: 32cm3
Collapsed Height: 51mm
Extended Height: 62mm
Outside Diameter: 101x76mm
